EasyLift by UPequip USA
THE Most Versatile Lift
Ready to put the 87-48AJ to work? Get a personalized quote from our US team — same-day response, delivered to all 50 states.
| Working height | 87′ |
| Horizontal outreach (265lbs) | 48′ |
| Total width | 35″ |
| Standard footprint + Narrow + mix | 14' 9" X 19' 0" |
| Overall weight | 8,300lbs |
| Overall stowed lenght | 21' 7" |
| Horizontal outreach (507lbs) | 42' |
The EPA Tier 4 Certified Kubota D902-E3B water cooled diesel engine with real 12V provides peace of mind. This extremely tough and quiet engine offers TVCS (Three Vortex Combustion System) for better emission and lower fuel consumption. The 208-240V AC electric motor allows drive and boom operation with no emission, when working indoors is required.
► VIDEO: Kubota & Electric motorsThe EPA Tier 4 Certified Kubota D902-E3B water cooled diesel engine with real 12V provides peace of mind. This extremely tough and quiet engine offers TVCS (Three Vortex Combustion System) for better emission and lower fuel consumption. The lithium-ion battery allows drive and boom operation with no emission when working indoors is required.
This configuration is made for those who primarily work indoors. Equipped with the world record holding company for long range vehicle battery operation Kaitec lithuim-ion battery pack. No wire, no combustion and no boundaries. The ultra-fast charger can be powered by either 110V or 208-240V AC power.
Offering reach even 20 degrees passed the 360 degrees “all around the clock” point, this great feature allows working at multiple areas from the same stabilization spot and is forgiving when you haven’t started in the right direction.
► VIDEO: rotation with outriggers in Narrow modeAll units are equipped standard with GFI double outlet, with cable running through the boom. Perfect to use electric tools up in the basket.
The standard lightweight aluminum detachable basket can be removed in seconds from the unit to allow insertion in tight places, doors, gates, etc. Optional casters can be installed on baskets so they can be transported easily.
► VIDEO: Basket removal Large unitsFor faster and more efficient troubleshooting from basket and base, the easy-to-read pilot lamps will quickly tell which condition isn’t met or what the current situation is.
► VIDEO: Description of a Main BoxOn top of being safe due to their location on the machine and the fact that no spreader bars are required, top mount lifting points allow you to insert your unit in even harder-to-reach areas and places with a crane.
► VIDEO: unit lifted with craneStrategically positioned tie-down anchor points in the back and front of your unit will ease your transport on a trailer.
The last section before the basket is called the jib. It is live even at full basket weight capacity. It offers maximum flexibility for a perfect final positioning at the working area. It also can be elevated while driving to allow better clearance of obstacles. On this unit, the amplitude of the jib is 140 degrees, allowing a total clearance of basket for all types of circumstances. It also allows a 10 foot height flexibility without touching the main booms.
► VIDEO: Unequalled jib amplitude demonstrationA standard 3000 PSI air/water line runs from ground to basket through the boom to offer more flexibility and less weight in the basket.
With the activation of a single button, your unit will level in a perfect way, regardless of the surface. A nice-to-have option to consider if moving your unit often is required.
Providing a major increase in both stability and weight distribution, extra-long black rubber tracks also provide an enhanced climbing capability to your unit. Made of durable rubber with a steel belt reinforcement, they are built to last.
All pivot points are easily accessible to prevent jerking, squeaking and insure a smooth pivot articulation.
All hoses and harnesses are routed inside of the boom, and protected by a heavy duty unbreakable patented telescopic power track. All hoses and harnesses can be inspected and replaced quickly right on the job site.
The anti-overload system is designed to prevent operation of a unit with an overloaded basket. An alarm and a red light, both at base and basket, will warn you. This system can be verified by operator during daily inspection.
Execute rapid emergency maneuvers with REAL live hydraulic joysticks for precision and safety in the movements. Get your operator down without stumbling in the process.
► VIDEO: LIVE hydraulic emergency controlsBringing a harmed operator or broken basket control to the ground is always possible from the base using the emergency descent procedure. The electric 12V emergency pump just makes it easier since no manual pumping is required to move the oil and build pressure.
► VIDEO: Difference between manual & 12V electricAll Easy Lift units’ booms and structural components are made from Swedish high tensile flexible Domex SSAB steel. It allows the production of smaller, yet more resistant components.
► VIDEO: Boom flex demonstrationThe passive stability management system is a working envelope monitored by several sensors and put together by a flow control. It is designed to prevent dangerous movements.
The hydraulic compensation system will keep the basket leveled to the ground all the time without any interaction required from the operator. For specific needs and tricky situations, there is a manual override.
This audible alarm will go as long as the unit moves, in combustion or electric mode. With safety standards present and future, this is a great safety asset.
The wind factor needs to be considered at all time when working in heights. Easy Lift units are fully safe under 28 Mph.
Despite all your planning and care, accidents unfortunately happen. The 1/4-inch heavy duty thick aluminum plates composing the hostile kit will greatly minimize the impacts of such accidents on vital components of the unit: ground lever controls, outrigger switches and cylinders.
With increasing safety regulations, this small option will soon make a huge difference and determine whether you will be able to go or not on a jobsite. Well worth it!
The last section before the basket is called the jib. It is live even at full basket weight capacity. It offers maximum flexibility for a perfect final positioning at the working area. It also can be elevated while driving to allow better clearance of obstacles. On this unit, the amplitude of the jib is 140 degrees, allowing a total clearance of basket for all types of circumstances. It also allows a 10 foot height flexibility without touching the main booms.
► VIDEO: Unequalled jib amplitude demonstrationThis is defined by how easy will you be able to climb any given obstacle (stairways, slopes, crosswalks, etc.) with limited use of ramps, wood blocks or else. The knowledge of this standard Easy Lift feature is crucial to make the best choice. This will be a blessing each and every time the unit will be used.
► VIDEO: Climbing ability vs departure angleThere are multiple outrigger positions since every outrigger is mounted on a swing-out pivot, allowing standard position (wide), narrow position or, for crowded floors, it is possible to mix positions for more flexibility.
► VIDEO: Turret rotation amplitude demonstrationAll units are equipped with independently operable high speed booms, allowing far better insertion strategies and a lot more flexibility.
With the activation of a single button, your unit will level in a perfect way, regardless of the surface. A nice-to-have option to consider if moving your unit often is required.
The wireless remote control will take charge of all movements for drive, outriggers and boom operations from ground. It also provides the best wireless perspective and flexibility when driving in tight places. An on-board battery charger and extra battery are included.
► VIDEO: Short demonstration of wireless remoteAll units are equipped standard with GFI double outlet, with cable running through the boom. Perfect to use electric tools up in the basket.
A standard 3000 PSI air/water line runs from ground to basket through the boom to offer more flexibility and less weight in the basket.
Never leave black marks anymore on any surface: concrete, brick patio, stone, marble, wood, epoxy coating, and so on. You will drive on non-marking tracks with peace of mind and won’t need to bite on your profit to clean up afterwards.
► Video comparing black vs non-marking tracksAlthough it is far more convenient to be two men to move a basket, casters will make your task possible even if you’re alone. No need to carry a dolly, just pure efficiency.
► VIDEO: How easy to move basket with castersOnly one 110V AC standard plug is necessary to warm your hydraulic oil tank, maintain your battery fully charged and insure that your unit will start in cold weather. A must-have option for those whose next project is a garage for equipment.
For a better view of the working area, under all circumstances, this powerful lamp will bring the sun everywhere.
The electrical system is composed of standard 12V, North American, easy to find, Solid State, and compatible components. No hassle in finding 24V parts!
Wear pads can be adjusted easily, no shimming required. Most can be replaced without the need to de-booming for extra convenience.
All pivot points are easily accessible to prevent jerking, squeaking and insure a smooth pivot articulation.
All Easy Lift units’ booms and structural components are made from Swedish high tensile flexible Domex SSAB steel. It allows the production of smaller, yet more resistant components.
► VIDEO: Boom flex demonstrationAll hoses and harnesses are routed inside of the boom, and protected by a heavy duty unbreakable patented telescopic power track. All hoses and harnesses can be inspected and replaced quickly right on the job site.
Multi-layer powder coat baked paint is applied before parts assembly, offering the same protection everywhere on parts. Customs colors are available in option.
Despite all your planning and care, accidents unfortunately happen. The 1/4-inch heavy duty thick aluminum plates composing the hostile kit will greatly minimize the impacts of such accidents on vital components of the unit: ground lever controls, outrigger switches and cylinders.
Only one 110V AC standard plug is necessary to warm your hydraulic oil tank, maintain your battery fully charged and insure that your unit will start in cold weather. A must-have option for those whose next project is a garage for equipment.
The outriggers needs some travel when they lift tracks off the ground. There are a few options available: 16 X 24 or 20 X 40 with or without sliding rails. Custom-made Teflon pads are designed to insure best load of each leg as well as best performance overall for operator.
Although it is far more convenient to be two men to move a basket, casters will make your task possible even if you’re alone. No need to carry a dolly, just pure efficiency.
► VIDEO: How easy to move basket with castersMulti-layer powder coat baked paint is applied before parts assembly, offering the same protection everywhere on parts. This option will allow color matching through the RAL International Color Code to paint your unit with your own company colors.
Very popular in the Utility and Tree Care markets, the one-man fiberglass basket will bring even more efficiency to those who often work in very tight places and hard-to-reach areas. There is no need to remove it at insertion and its dimensions makes it easy to insert within structures, branches, etc.
This 2-Man fiberglass basket provides more flexibility regarding what tools can be carried up for work. The fiberglass makes insertion in branches as smooth as it can be.
With increasing safety regulations, this small option will soon make a huge difference and determine whether you will be able to go or not on a jobsite. Well worth it!
Only one 110V AC standard plug is necessary to warm your hydraulic oil tank, maintain your battery fully charged and insure that your unit will start in cold weather. A must-have option for those whose next project is a garage for equipment.
Without a doubt purchasing a lift from UPequip was one of the most lucrative purchases in my career . As a 20 year tree climbing veteran it was a nice break up in the daily grind to not have to climb everything all the time. I love climbing but you simply cannot beat the production…
It’s been a while since I’ve posted anything here, but I felt compelled to share my experience with the folks @ UP Equipment. While I haven’t bought a significant number of brand new pieces of machinery, I have had years of experience trying to work with manufacturers to dial out the bugs and difficulties with…
As a customer from the US, I was a little apprehensive about buying equipment from a vendor in Canada for when repairs/maintenance issues arose, but UPequip has been very helpful and prompt in answering any questions we've had regarding our lift. Their customer service is excellent and they have always made getting my equipment back…
UpEquip has been valuable asset to our business. As an equipment rental company, our 70-36A spider lift was a phenomenal addition to our fleet. Alain was incredibly helpful during the buying process, and we know their service department is a quick phone call away should we need any assistance. Highly recommend!
I purchase a 61-36A machine a couple of years ago. Overall, I’m very happy with the machine and extremely happy with the service I’ve received from UPEquip. The machine suits my needs very well and have had few problems. I have had a few issues with electrical problems.. The AC/DC converter went bad twice but…
I purchased an EasyLift 87-48AJ from Up Equipment in March of 2020. It has done an excellent job for us, more than doubling production on any job requiring a climber. In fact, I no longer employ a climber. If I cannot get the EasyLift close enough to a tree on a prospective job, I simply…
If it breaks, we fix it so you can get back to work ASAP: that’s the UPequip promise.
With Easy Lift, you’re part of the family. We’ve got you covered!
Select your power configuration, options and delivery state. Our US team responds the same day with transparent pricing and expert guidance — no pressure, no surprises.
Prefer to talk? Call 1-844-UPEQUIP — real people, real answers, same day.
